Product Description
The in-ear personal wireless monitoring system, with efficient and reliable radio frequency performance, can transmit stable audio carrier signals over a visual range of 80 meters, which can bring maximum freedom to every corner of the stage.
1. Using UHF frequency band, PLL phase locking circuit, stable characteristics, low harmonic radiation.
2. LCD display, function selection and adjustment are operated by button mode.
3. The transmitter and receiver independently have mono and stereo modulation functions.
4. The excellent circuit design achieves the best signal-to-noise ratio and reduces auditory fatigue to a limited extent.
5. The receiver has a sound channel volume balance control design, which is convenient for users to adjust to the desired volume.
6. The transmitter has a 6.3 (mm) stereo headphone output monitor socket, and the minimum headphone impedance is 16Ω
Stereo monitor launch
Number of channels: single channel
Frequency range: 500-960MHz
Frequency stability: ±0.005%, PLL
Modulation: FM stereo
Bandwidth: 30MHz
Signal to noise ratio: >105dB
Harmonic distortion: <0.4% @ 1KHz
Frequency response: 40Hz-16KHz ±3dB
Effective use distance: 80m
Stereo monitor reception
Number of channels: single channel
Frequency range: 500-960MHz
Frequency stability: ±0.005%, PLL
Modulation: FM stereo
Bandwidth: 30MHz
Signal to noise ratio: >105dB
Harmonic distortion: <0.4% @ 1KHz
Frequency response: 40Hz-16KHz ±3dB
Effective use distance: 80m
