DSP2060

Category:

Audio equipment

Inquiry Now

Keywords:

DSP2060

Product Description

2 group input, 6 group output
Filter type: 12 dB/Oct，18 dB/Oct，24 dB
Oct and 48dB/Oct / 682ms input delay，21ms output delay
with Linkwits-Riley，Bessel and Butterworth filter
Parameter equalizer：full bandwidth，1/36 to 4 range
Sampling frequency: 96 KHz
Output：6-way electronic balance
Maximum level：+15dBm
Dynamic range：﹥105dB 20HZ-20KHZ
Gain：+15dB≈-30dB，0.1 dB
parameter equalizer：3 band input，5 band output
Frequency response: 20Hz - 22kHz, +/-0.2dB
SNR: 110dB Typical (Unweighted)
Distortion: <0.0029% @1K,0dBu
Audio plug：XLR
Control plug：RS232 DB-9; USB type
Power supply: 100~230V AC, 50/60Hz
Dimensions: 483mm x 210mm x 45mm
Weight: 3.1kg
